Timing Formats
- 12G-SDI Quad-Link 8K 60/59.94p YCbCr 4:2:2 10 bits (SMPTE 2082-12)
- 12G-SDI Dual-Link 8K 30/29.97p YCbCr 4:2:2 10 bits (SMPTE 2082-11) *
- 12G-SDI Single-Link 4K 60/59.94p YCbCr 4:2:2 10 bits (SMPTE 2082-10)
- 6G-SDI Single-Link 4K 30/29.97p YCbCr 4:2:2 10 bits (SMPTE 2081-10)
(* 12G-SDI Dual Link output is treated as reference)
Features
- 12G-SDI signal 8K 60/59.94p YCbCr 4:2:2 10 bits
- 12G-SDI signal 4K 60/59.94p YCbCr 4:2:2 10 bits
- Supports ITU-R BT.2020
- Audio 32ch can be embedded
- Payload ID can be embedded
- Time code can be embedded
- HDR supported.
- Reference input support (Internal synchronization / external synchronization selectable)
- Supports external control (LAN / RS-232C)
Pattern
- Color bar (100% / 75%)
- Raster (White / Gray)
- Check field (Pathological)
- Ramp
- Crosshatch
- Multiburst
- Black
Specifications
| VG-886 | ||
|---|---|---|
| VIDEO | Number of output terminals | 4ch |
| HD-SDI | SMPTE 274M, | |
| 3G-SDI | SMPTE 425-5, 425-1 | |
| 6G-SDI | SMPTE 2081-10 | |
| 12G-SDI | SMPTE 2082-12, 2082-10 | |
| Gradation | 10bit | |
| Colorimetry | Rec.ITU-R BT.2020R/Rec.ITU-R BT-709 | |
| AUDIO | Number of channels | 32ch |
| Sampling frequency | 48kHz | |
| Resolution | 24bits | |
| Audio level | -18dBFs / -20dBFs | |
| Audio frequency | 1kHz | |
| PAYLOAD | standard | SMPTE ST2082 / ST425-1(Byte2) reference |
| Insertion code | Normal insertion | |
| TIMECODE | standard | SMPTE 12M-2, 12M-3 |
| Time code | VITC TIMECODE LTC TIMECODE HFRTC TIMECODE |
|
| REFERENCE | Interface | 75 Ω BNC input 1 line / 2 lines output |
| reference | Internal synchronization / external synchronization | |
| Sync output | 525 NTSC BB signal, 625 PAL BB signal, 1125 HDTV Tri-level synchronization signal (1125/60i , 1125/59.94i ） |
|
| External control | |
|---|---|
| RS-232C | D-sub 9-pin 9600/19200/38400/57600 bps |
| LAN | 100BASE-T / 100BASE-TX |
| General Specıfıcatıons | |
|---|---|
| Power Consumption | 20W MAX |
| Power Requirements | DC 12V |
| Operating temperature range | 5～40℃（No condensation） |
| Operating humidity range | 20～85％（No condensation） |
| Dimensions | 210(W)mm×44(H)mm×350(D)mm (1U half, Excluding protrusions） |
| Weight | Approx. 2.0kg |
Front / Rear
