APPLICATION
9 test ranges ,200pF~20mF
FEATURES
-
LCD : 3½ digits LCD a maximum reading of 1999.
-
Overload indication:LCD display “1” in the left highest position.
-
Zero adjustment , ±20pF approx.
-
Display rate : 0.5second ,approx.
-
Operating Temperature & Humidity :
-
0℃~40℃ below 80%RH.
-
Storage temperature & Humidity :
-
-10℃~ 60℃ below 7% RH.
SPECIFICATIONS
-
Dimension: 4143mm(L)x74mm(W)x39mm(H).
-
Weight:about 267g. (Including battery)
|
Rang
|
Resolution
|
Accuracy
|
Max imum display
|
test frequency
|
Overload peotection
|
|
200pF
|
0.1pF
|
±(0.5%+1+0.5pF)
|
199.9pF
|
819.2Hz
|
0.1A/250V fuse
|
|
2000pF
|
1pF
|
±(0.5%+3)
|
1999pF
|
||
|
20nF
|
10pF
|
19.99pF
|
|||
|
200nF
|
100pF
|
199.9nF
|
|||
|
2μF
|
1nF
|
1.999μF
|
|||
|
20μF
|
10nF
|
19.99μF
|
81.92Hz
|
||
|
200μF
|
100nF
|
199.9μF
|
8.912Hz
|
||
|
2000μF
|
1μF
|
±(1%+1)
|
1999μF
|
||
|
200mF
|
10μF
|
±(2%+1)
|
19.99mF
|
||
|
※pF=10-12F, nF=10-9 F. uF=10-6F, mF=10-3F,
※Test Voltage < 3.2V
|
|||||
