APPLICATION
It is capable of measuring the electromagnetic field radiation intensity that is produced from electric transmission equipment, power line, air conditioner, refrigerator, computer monitor, video/audio device and so forth.
FEATURES
-
Switch between the display of micro-Tesla and mini-Gauss is available.
-
Data hold (HOLD)、maximum (MAX) Hold function.
-
Range display(20,200,2000).
-
Low battery detector .
-
Over load display “OL”.
SPECIFICATIONS
-
Display: 3½ digits LCD, maximum reading 1999.
-
Range: 200/2000 mG,20/200µT.
-
Resolution: 0.1/1 mG or 0.01/0.1 µT.
-
Frequency response: 30Hz to 300Hz.
-
Sensor: Single Axis
-
Accuracy: ±(2.5%±6dgt) at 50Hz/60Hz.
-
Over load: LCD display “OL”.
-
Sample rate: 2.5 times per second.
-
Battery: 9V NEDA 1604, IEC 6F22 or JIS 006P.
-
Battery life: Approximate 100 hours.
-
Operating temperature & humidity: 5°C~40°C,below 80% RH.
-
Storage temperature & humidity: -10°C~60°C, below 70%.
-
Weight: About 170g.
-
Dimensions: 140(L)*65(W)*37.5(H)mm.
ACCESSORIES
-
User’s manual
-
9V battery
-
Carrying case.
