♦ Convenient data entry via knob or numerical key pad
♦ High accuracy and high resolution
♦ Remote sense
♦ Output voltage and current values accordance with procedure
♦ Adjust voltage and current via Knob
♦ Low ripple and low noise
♦ OVP, OTP
♦ Built-in RS232/USB/GPIB interface *1
♦ Monitor software via PC
♦ Support SCPI command, compatible IT6800 frame format protocol
*1 Only IT6800B dual range series have built-in GPIB communication interface,
Functions and Advantages
IT6860A series DC power supply offers high and low voltage range for your choice. When needing high voltage output, high voltage is optional, when needing high current, low voltage is optional.
CV/CC automatic conversion function
With this function, the power supply can be operated continuously with the change of load from cv mode to cc mode. For the current load, the power supply operates in constant voltage mode and the power supply will provide a controlled output voltage. With the decrease of load resistance value , the output voltage drop remains constant until the current increases up to preset current Value, and then the conversion occurs. At this time the power supply becomes constant current output, and the output voltage will be reduced in proportion according to the further reduce of load resistance value. When the current value is lower than the set value, the power supply returns to the constant voltage mode.
Output timer Function
This series supports output timer function, in ON mode, the indicator light “Timer” will be lit on the VFD screen. When output of power supply is opened, timer will begin to work, after reaching the definite time, output will be off automatically. Timing output time range is 0.1s~9999.9s or 0.1m~9999.9m.
