APPLCIATION
-
Building HVAC monitoring.
-
Warehouses.
-
Refrigerator.
-
Clean rooms.
-
Freezer.
-
Shipping vans.
-
Shipping crates.
-
Cargo vessels.
-
Storage areas.
FEATURES
-
The data is directly transferred to computer via USB cable, the docking station is not required
-
Waterproof IP 54
-
Hi-Low set-up alarm
-
USB interface for set-up and data download
-
Fast USB download speed-download 50,000 records in less than 10 seconds
SPECIFICATIONS
-
Display : 3 digit LCD.
-
LED status: red LED of Alarm, greed LED of Record.
-
Sampling rate: 1 times/3 second.
-
Battery : One 3.6V ½ AA lithium battery
-
Battery Lift :1 year.
-
External Power Supply: 5 VDC with 0.5A.
-
Operating temperature and humidity : -40 to 85℃(-40~185℉), 0-95%,RH,non-condensing.
-
Instrument dimensions :83(L)*60(W)*24(H) mm.
-
Weight : About 77g.
|
Temperature Sensor
|
|
|
Measurement Range
|
-40~185°F(-40~85°C)
|
|
Accuracy
|
±0.6°C(±1.2°F)from
-20-50°C(-4~122°F) ±1.0°C(±1.8°F) all other ranges
|
|
Resolution
|
0.1°C
|
ACCESSORIES
-
User’s Manual
-
3.6V ½AA lithium battery
-
USB cable
-
Installation disk
