iLDM-150/100H/120H/150H/160H
Professional Laser Distance Meter

The professional Laser Distance Meter is designed to give special users a high accuracy, one person distance measuring and estimating tool to measure remote and difficult reaching places. The compact and handheld design for indoor applications.Shortcut keys for addition, subtraction, Pythagoras, area and volume calculation make measuring fast and very reliable. The last 20 measurements are also stored.
Meterbox-iLDM software & cloud server support to transfer the measured data to the customer’s smartphone for edit and storage.

iLDM-150 with Meterbox-iLDM Pro Software support our laser distance meter transfering the measured data to the customer smartphone.

Four application mode:

  • Family decorating
  • Construction and acceptance
  • Normal distance measuring

Software Functions:

  • Distance measuring data transferred to Cloud
  • Edit, analysis & Store the distance data
  • Connecting with iPhone / iPod / iPad / Android Phone / Android Pad
  • Sharing the data with others by E-mail, facebook & twitter
  • Trend capture
  • Cloud backup

FEATURES

Area, Volume Calculations
Indirect Measurement Using Pythagoras
Indirect Measurement Using Tilt Sensor
Angle Measurement Using Tilt Sensor (±65°)
Addition/Subtraction
Continuous Measurement
Min/Max Distance Tracking
Timer (self-triggering)
Laser Continuous
Stake-out Function
Display Illumination and Multi-line Display
Multifunctional Endpiece
Tripod Thread
Bluetooth with APP Support
Meterbox iLDM & Cloud Service

Size(HxWxD): 135mm x 58mm x 33mm

Weight: 203g

SPECIFICATIONS

Specifications iLDM-150 iLDM-100H iLDM-120H iLDM-150H iLDM-160H
Measuring Range 0.05 to 70m (0.15ft to 229.0ft) 0.05 to 100m (0.15ft to 328.0ft) 0.05 to 120m (0.15ft to 393.7ft) 0.05 to 150m (0.15ft to 492.1ft) 0.05 to 160m (0.15ft to 524.9ft)
Measuring Accuracy Typically ±1.5mm (±0.06in)
Measuring Units m, in, ft
Laser Class Class II 635nm, <1mW
Smallest Unit Displayed 1mm
Tilt Sensor Measuring Range ±65°
Range of Bluetooth 10m
Dust Protect/Splash Proof IP54
History Measurement Records 99
Keyboard Type Super Soft-touch (Long Life)
Operating Temperature -10℃ to 50℃ (14℉ to 122℉)
Storage Temperature -20℃ to 60℃ (4℉ to 158℉)
Battery Life Up to 8,000 Measurements
Battery Type AA 2×1.5V
Auto Laser Switch-off After 0.5min
Auto Instrument Switch-off After 3min

ACCESSORIES

Accessories:

2 x 1.5V AA batteries and gift box with carrying case.
