APPLICATION
- Building HVAC monitoring.
- Indoor air quality survey.
- Locate the presence of combustion fumes from vehicles and appliances
FEATURES
-
3 Independent CO2, humidity and temperature sensors.
-
User operated CO2 calibration.
-
USB datalogg: 50,000 records.
-
Internal backup battery to maintain date/time setting.
-
Power management IC to increase batter efficiency.
-
Easy- to-Use PC software for parameter settings and data analysis.
-
Internal CO2 alarm buzzer.
Power Supply Battery 4 AA batteries Battery operation 24 hours External power supply 5V~6V VDC with 0.5A
SPECIFICATIONS
-
CO2 Sensing Method: NDIR (Non-Dispersive Infrared)
-
Measures: Carbon dioxide in PPM, temperature (F or C), % Relative Humidity
-
CO2 Measurement range: 0~9999 ppm (2001~9999 ppm over range)
-
CO2 Accuracy: ± 60ppm, ± 5% of reading (0~2000 ppm)
-
Display Resolution – ±1 ppm
-
Datalogging:17,000 records,
-
Fast USB download (50,000 records in less than 10 seconds.)
Electrical specifications
|
CO2 Sensor
|
|
|
Type
|
Non-dispersive infra-red (NDIR)
|
|
Measurement
range
|
0~9999ppm
|
|
Accuracy
|
±60ppm or ±5% of reading
|
|
Resolution
|
±1ppm
|
|
Response time
|
Reaches 90%
in approximately 2 minutes
|
|
General
|
|
|
Operation condition
|
32°F~122°F (0°C~50°C)
|
|
0~95%,RH,non-condensing
|
|
|
Storage temperature
|
-4°F~140°F (-20°C~60°C)
|
|
Relative Humidity Sensor
|
|
|
Type
|
CMOS Sensor
|
|
Measurement range
|
1%~99%
|
|
Accuracy
|
±3.0%RH (20%~80%) at 25°C
±5.0%RH (<20%,>80%) at 25°C
|
|
Resolution
|
0.1%
|
|
Response time
|
8 seconds
|
