APPLICATION
-
Evaluation of environmental noise
-
Measurements of noise at workplaces
-
Assessment of product noise
FEATURES
-
Readings display: two rows with maximum value at 1999.
-
Lower power detection, backlight function, data lock function (HOLD)
-
Auto power On/Off function
-
Overload display: “OVER” or “UNDER”
-
Storage interval: 1 second~ 24 hours; up to 35,000 records.
-
Power consumption at standby mode: 10uW
-
Power consumption at operation mode: 250mW
SPCIFICATIONS
-
Dimensions:285x90x39mm(length x width x height).
-
Weight: Approximately 500 grams.
Electrical Specifications
|
Display Refresh Rate
|
One time per second
|
|
Major Applicable Standards
|
IEC 61672-1：2002 Class1
IEC60651:1979 TYPE 1
IEC60804:2000 TYPE 1
|
|
Microphone
|
High sensitivity,
½”pre-polarized capacitor microphone 50 mV/Pa |
|
Measurement Items
|
Lxyp,Lxmax,Lxmin,Lxeq,LAE,Lcpeak
|
|
Measurement Range
|
30dB ~ 130dB (A)
35dB ~ 130dB (C)
40dB ~ 130dB (Z
|
|
Dynamic range
|
60 dB
|
|
Measurement shift
|
30dB ~ 90dB (L)
50dB ~ 110dB (M)
70dB ~ 130dB (H)
|
|
Integrate Time Setup
|
Manual, 10s, 1m, 5m, 10m , 30m,
1h, 8h, 16h, 24h |
|
Micro SD Card
|
The max support capacity of
micro SD card is 32GB； 37,000 data about story space 300KB |
|
Peak value
measurement range |
70~133 dBC
|
|
Time Weighting
|
Fast, Slow, Impulse, Peak
|
|
Frequency Weighting
|
A/C/Z
|
|
Frequency Range
|
20Hz~16KHz
|
|
DC Output
|
10mV/1dB
|
|
AC Output
|
1Vrms(±10%)/130dB each range
|
|
Starting Time
|
＜10 Second
|
|
Thermal noise
|
≦28dBA
|
ACCESSORIES
-
User’s manual
-
AC to DC adaptor
-
Windscreen ball
-
Installation disk
-
USB Cable (Mini B type)
-
AC adapter(9~12V/500mA)
-
1.5V AA-LR6-AM3 ailkaline battery
