- HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant
- Scales any HD resolutions to PC (VGA ~ WUXGA)/ HD (480i ~ 1080p) resolutions
- Automatically detect the factory setting of the connected display and output the corresponding resolution and refresh rate, when the NATIVE output is selected
- Provides output picture adjustment on contrast, brightness, hue, saturation, sharpness, RGB (color tone) level and aspect ratio size
- Supports high resolution output:
- PC: VGA, SVGA, XGA, SXGA, UXGA, WXGA, WSXGA and WUXGA
- SDTV/HDTV: 480i, 576i, 480p, 576p, 720p, 1080i and 1080p
- Supports stereo LPCM analog/digital audio input and stereo LPCM analog/digital output
Inputs
- 3x RCA [1x YCbCr Component]
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
- 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
Outputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
- 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
PSU:
- 5V/2.6A
Dimensions
- 154mm [W] x 100mm [D] x 25mm [H]
Net Weight
- 340gr
