EGE-VGA-444A
Input/output: VGA port and 3.5mm stereo audio
Singal type: VGA, RGBHV, RGBS, composite video, component video
Height: 1U
Bandwidth: 450MHZ
Input level: 0.5V2 : 2V p-p
Output impedance: 75 Ω
Crosstalk: -30 dB. 5MHz
Switching speed: 200 ns (maximum)
Highest Resolution: 2048×1536
Max Input/Output: < 40m
Serial Control Interface: RS-232 DB9 male
Baud rate and protocol: Baud rate: 9600, data bit: 8, stop bit: 1, no parity
Structure of serial control interface: RS232 IN:2 = TX, 3 = RX, 5 = GND /RS232 OUT: 2 = RX, 3 = TX, 5 = GND
Switch methods :(Button press, RS232, IR remote) default
(ethernet, app on phone, ipad) Optional
Consumption: < 20W
Power: DC 5V
Temperature Storage and operating temperature: -20°~ +50°C
Humidity Storage and operating humidity: 15% ~ 85%
MTBF: 29000 h
Assembly: 1 U rack-mountable
