- HDMI 1.4 with 3D, 4k2k support, HDCP & DVI Compliant
- Supports CEC bypass
- Contemporaneous transmittal of uncompressed data over a single 100m/328ft CAT5e/6 cable
- Uncompressed video 1080p, 60Hz, 36-bit
- Audio support up to 7.1CH & Dolby TrueHD, DTS-HD Master Audio
- HDBaseT 5Play™ convergence: HDMI, LAN, PoE & Control (IR & RS-232)
Inputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x RJ45 [1x LAN Serving]
- 1x 9-pin D-sub [1x RS-232 Data]
- 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]
Outputs
- 1x RJ45 [1x HDBaseT HDMI & Propriety Data]
- 1x 3.5mm Stereo Mini-jack [1x Infrared Emitter]
PSU:
- 24V/1.25A
Dimensions
- 102mm [W] x 113mm [D] x 25mm [H]
Net Weight
- 252gr
