- Supports single Coaxial input to Coaxial signal output
- Supports single Optical input to Optical signal output
- Supports Optical or Coaxial digital audio S/PDIF signal (sampling rate 96 kHz)
- Supports digital audio formats: LPCM 2 CH, Dolby Digital or DTS 5.1 CH
- Supports industry standard category 5/5e/6 cable
TRANSMİTTER:
Inputs
- 1x TOSLINK [1x 2 Channel LPCM / Dolby Digital / DTS]
- 1x RCA [1x 2 Channel LPCM / Dolby Digital / DTS]
- 1x USB Mini-B [1x USB Power]
Outputs
- 1x RJ45 [1x Digital Audio Propriety Data]
PSU:
- 5V/1A,USB powered
Dimensions
- 70mm [W] x 70mm [D] x 22mm [H]
Net Weight
- 50gr
RECEİVER:
Inputs
- 1x RJ45 [1x Digital Audio Propriety Data]
- 1x USB Mini-B [1x USB Power]
Outputs
- 1x TOSLINK [1x 2 Channel LPCM / Dolby Digital / DTS]
- 1x RCA [1x 2 Channel LPCM / Dolby Digital / DTS]
PSU:
- 5V/1A,USB powered
Dimensions
- 70mm [W] x 50mm [D] x 22mm [H]
Net Weight
- 50gr
