[ Input System ]
| Interface | Format | |
|---|---|---|
| Full Resolution 8K 12G-SDI Input Level A Compatible |
BNC connector × 4 lines 2-sample interleave division format 7680 × 4320 YCBCR 10bits each 60Hz/59.94Hz |
|
[ Output System ]
| Interface | Format | |
|---|---|---|
| HDMI Output | HDMI connector × 4 7680×4320 60Hz/59.94Hz RGB 4:4:4 8bit 7680×4320 60Hz/59.94Hz YCBCR 4:2:2 12bit 7680×4320 60Hz/59.94Hz YCBCR 4:2:0 8bit |
|
