- Compliant with HDMI (with Deep Color Video), HDCP 1.1 and DVI 1.0
- Supports up to 1080p@50/60 and WUXGA
- Supports pixel component format with RGB: YCbCr422: YCbCr444
- Supports bit depth per color with 8/10/12-bit
- Bi-direction Color Space Conversion (CSC) between RBG and YCbCr
- Dithering for conversion from 12-bit component to 10/8-bit
- Support USB 2CH, LPCM 48K@24-bit
- Automatic audio error detection with soft mute function, preventing annoying harsh output sound due to audio error or hot-unplug
- Automatic loss of signal detection for link management
Inputs
- 1x DisplayPort [1x mDP Uncompressed Video]
- 1x USB Mini-B [1x USB Audio / USB Power]
Outputs
- 1x HDMI [1x Uncompressed AV and Data]
PSU:
- USB powered
Dimensions
- 100mm [W] x 62mm [D] x 22mm [H]
Net Weight
- 22g
