AIM Series in-ceiling speakers were the first to feature an aimable woofer/tweeter module that aims the sound in any direction you choose. No longer are you bound by the design of your room. Just mount the speakers wherever it’s convenient and point them wherever you want sound. Profile grilles are available in AIM8, AIM7 and AIM5 models.
SPECIFICATIONS
- Flangeless Appearance
- Pivoting 1″ Silk Dome Tweeter
- Two 5¼” Injection Molded Graphite Cone Woofers with Phase Plugs
- Two 6″ Kevlar® Impregnated Paper Cone Woofers
- Front-Mounted Bass Adjustment Switch
- Bi-Amping Feature
OTHER SPECIFICATIONS
| General | |
| Family | Profile AIM Cinema |
| Woofer Size | 5.25 (Inches) |
| Woofer Construction | Two 5¼” Injection Molded Graphite Cone Woofers with Phase Plugs . Two 6″ Kevlar® Impregnated Paper Cone Woofers |
| Frequency Response | 40Hz – 20kHz |
| Impedance | 8 (Ohms) |
| Sensitivity | 89 (dB) |
| Timbre | Timbre-Matched to All One Series Speakers |
| Dimensions | (H x W x D) 30 1/4″ x 9″ x 4″ (768 mm x 229 mm x 102 mm) (with Grille) |
| Hole Cutout Dimensions | (H x W) 28 3/4″ x 7 1/2″ (730 mm x 191 mm) |
| Shipping Info | |
| Length | 33.3 (Inches) |
| Width | 8.2 (Inches) |
| Height | 11.6 (Inches) |
| Weight | 17.15 (Lbs) |
| Unit of Measure | Each |
| Master Pack Qty | 2 |
| Other Specifications | |
| Flangeless Appearance | |
| Pivoting 1″ Silk Dome Tweeter | |
| Two 5¼” Injection Molded Graphite Cone Woofers with Phase Plugs | |
| Two 6″ Kevlar® Impregnated Paper Cone Woofers | |
| Front-Mounted Bass Adjustment Switch | |
| Bi-Amping Feature |
