- 30 watts per channel Digital Stereo Amplifier
- Supports Digital to Analog audio Conversion (DAC) and Analog to Digital audio Conversion (ADC)
- HDMI audio embedding and de-embedding
- Supports input audio sampling rates up to 96kHz and output at 48kHz
- Supports HDMI audio sampling rates loop-through and video bypass output
- Supports a wide range of resolutions from 480i to 1080p and VGA to WUXGA(RB)
- Dedicated XLR microphone input with independent volume control
- Supports microphone sound being embedded into video output
- Simultaneous output of sound on both digital and analog
- Analog line output selectable to be either fixed or variable output level
- Supports control via IR (Remote and IR Extender input), RS-232 or IP (Telnet/Web GUI)
- Compact design and easy to use
Inputs
- 2x HDMI [2x Uncompressed AV and Data]
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
- 1x RCA [1x COAX 2 Channel LPCM]
- 2x RCA [1x Stereo (L/R)]
- 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
- 1x 9-pin D-sub [1x RS-232 Data]
- 1x RJ45 [1x RS-232 Propriety Data]
- 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]
- 1x USB Type A [1x UPDATE Propriety Data]
Outputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
- 1x RCA [1x COAX 2 Channel LPCM]
- 2x RCA [1x Stereo (L/R)]
- 4x Speaker Binding Posts [1x Speaker Level Stereo Output]
PSU:
- 24V/3.75A
Dimensions
- 215mm [W] x 172mm [D] x 46mm [H]
Net Weight
- 1060g
