PRODUCT TRAIT
- 800*480 pixel, TFT colorful screen with touch functions, Peak/real-time value/force curve display at the same time.
- Free setting and judgement of up and down limit value
- Different test mode for different spring test requirements: Constant force mode, Constant displacement mode, constant force circle mode, constant displacement circle mode, constant force multipoint test mode, constant displacement multipoint test mode.
- Multipoint test, print and get severity
- Save 10 test value and 3 groups curve test, could view the value of every point on curve, test report could be printed by printer inside
- Four unit option: N、kgf、lbf、ozf, automatic exchange
- Automatic off mode without any operation, time is set freely
- Automatic back to start location after test finish
- Two speed mode, high speed approach and low speed collect
- High precision ball screw, better drive efficiency and high accurate displacement
- Servo drive system, low noise and good stabilization
- High accuracy sensor, promise test precision
Note:Due to updates and improvement,products shape and color depends on specific products.Please contact us if you have any problems.
