Clamps for Tension Tests

Pin Grip CP-150N

For gripping thin materials.

CP-150N: Sample diameter 3.2 mm, capacity 150 N

More information in the PDF:

Suitable for seal strength of corrugated cardboard.

DF-60: Width 60 mm, capacity 200 N

More information in the PDF:

Film Grip FC

Suitable to grip thin film test pieces.

Jaw face width: 20 – 100 mm

Capacity: 250 or 500 N

Opening width: Max. 2 mm

With or without urethane coating

More information in the PDF:

Fine Point Grip FP

For fine wires and narrow space. Opening width 0.5 mm.

FP-50: Capacity 100 N

FP-51: Capacity 50 N

ore information in the PDF:

Tape Grip GC

Self-tightening ”buckle-type” mechanism with serrated jaws ensures slip-free operation. For testing rubber, paper, films etc. up to 2 mm thickness.

GC-60: Sample width 30 mm, capacity 500 N

GC-100: Sample width 50 mm, capacity 500 N

More information in the PDF:

Fine Point Grip FP

Squared serrated face, heavy-duty flat grip for many applications.

GC-1100: Grip dimensions 20 x 20 (W x H), opening width 10 mm, capacity 1000 N (old order number: GC-1001)

GC-1200: Grip dimensions 20 x 20 (W x H), opening width 20 mm, capacity 1000 N (old order number: GC-1021)

GC-5000: Grip dimensions 29 x 37.5 (W x H), opening width 30 mm, capacity 5000 N

More information in the PDF:

Jacob`s Chucks GC

For use with shafts, rigid rods and small wires.

GC-5: Opening width 0.5 – 6.5 mm, capacity 500 N

GC-15: Opening width 2.0 – 13 mm, capacity 1000 N

More information in the PDF:

Cam Grip GP-30

For wire or soft samples.

GP-15: Opening width 4.5 mm, sample width 15 mm, capacity 250 N

GP-30: Opening width 10 mm, sample width 30 mm, capacity 1000 N

More information in the PDF:

Cam Grip GR

Eccentrically mounted, serrated roller grips allow for self-tightening of thin material.

GR-30: Sample width 30 mm, opening width 2 mm, capacity 500 N

GR-2000: Sample width 50 mm, opening width 4 mm, capacity 2000 N

More information in the PDF:

Wedge Grip KC

Spring loaded jaws automatically close on the specimen and tighten as tension is applied. For testing wires, stripes, tapes and films.

KC-100: Grip dimensions 15 x 22 mm (W x H), opening width 8 mm, capacity 500 N

KC-1001: Grip dimensions 9.8 x 15 mm (W x H), opening width 2 mm, capacity 1000 N

KC-5000: Grip dimensions 23.8 x 26 mm (W x H), opening width 5 mm, capacity 5000 N

More information in the PDF:

Attachment for loop tensile strength tests LOP-1000N

For testing the durability of cable ties.

Capacity 1000 N, max. sample width 10 mm

More information in the PDF:

Pantograph PGC

For wide purpose by wide open jaw grips.

PGC-0510: Opening width 15 mm, capacity 500 N

PGC-0505: Opening width 20 mm, capacity 500 N

PGC-2530: Opening width 15 mm, capacity 2500 N

More information in the PDF:

Button Tester PGC-BC/BC-15

Grip and vise to determine the tear-off force of sewed buttons Capacity 300 N

PGC-BC: Opening width 35 mm

BC-15: Button diameter max. 15 mm, button hight max. 3.5 mm

More information in the PDF:

Tape Grip PPC-5000N

For tensile tests on polypropylene strapping bands.

Sample width 40 mm, opening width 1 mm, capacity 5000 N

More information in the PDF:

Fine Point Grips SC

For testing small to medium diameter wires, small components, ribbon tapes. Opening width 1 mm.

SC-3: Width of jaw 3 mm, capacity 100 N

SC-8: Width of jaw 8 mm, capacity 150 N

More information in the PDF:

Double Arm Hook SHF

Suitable for tension test on caps.

SHF-100N: Sample size 30 x 30 mm

SHF-100N-L: Sample size 30 x 55 mm

More information in the PDF:

Wire Wrapping Grip WG

For measuring the strength of wires, filaments, fibres etc.

Wrapping a sample avoids breaking at the gripping point.

WG-250N: Capacity 250 N

WG-1000N: Capacity 1000 N

WG-5000N: Capacity 5000 N

More information in the PDF:

Flip Cap Opening Force Test Hook HFC-50N

For opening force test of plastic made flip caps.

Capacity 50 N

More information in the PDF:
