Multiple functions including “Angle Setting”, “Torque Setting”, “Unit Setting”, “Mode Setting”, “Data Storage”, “Data Clear”, “Data Output”
9 pre-settable target torque values
Functions in both clockwise and anticlockwise directions
LCD display showing N-m, ft-lb, in-lb, kg-cm and angle measurements
Data memory size (torque and angle) 50 or 250 optional
While using and the screen is invisible, the 12 LEDS would side visible to pro vide notice for target value
| Model | Range | Resolution | Drive Size |
|---|---|---|---|
| DTWA-30i | 1.5-30 Nm | 0.01 Nm | 1/4″ |
| DTWA-135i | 6.8-135 Nm | 0.1 Nm | 3/8″ |
| DTWA-135f | 6.8-135 Nm | 0.1 Nm | 1/2″ |
| DTWA-200f | 10-200 Nm | 0.1 Nm | 1/2″ |
| DTWA-340f | 17-340 Nm | 0.1 Nm | 1/2″ |
