11 Ranges up to 4,400 lbs
Easy-to-use menus make programming simple in eight languages. Select units, reverse display, set high/low setpoints, and all other functions in plain language.
Electroluminescent display (ELD) shows force value, unit, and peak, and can be configured with additional user-selectable data including memory data, +NG count, high/low setpoints, 1st and 2nd peaks, displacement value (using atest stand with FA option), etc.
Color-coded LED indicators alert the user to Go/NoGo conditions. Orange lights for less than low setpoint, green lights between high and low, and red for over the high.
Process and transmit 2,000 actual data per second, not just the peak from a high sampling rate. Optional Force Recorder data acquisition software is designed to process up to 2,000 data per second.
Display force and displacement data on ZTA gauges with test stands equipped with FA option.
Save data to USB flash drives. Export peak data or capture continuous data at 100 data/second to flash drives with ZTA force gauges.
ZT Logger data acquisition software downloads data from the gauge memory or captures a continuous stream of data at 10 data/second. Zero the gauge or capture data while at the computer. All gauge programming can be set and saved from the software.
Force Ranges
| Model | Capacıty | Resolutıon |
|---|---|---|
| ZTA-DPU-0.4 | 7.00 ozf 200.0 gf 2.000 N |
0.01 ozf 0.1 gf 0.001 N |
| ZTA-DPU-1 | 18.00 ozf 500.0 gf 5.000 N |
0.01 ozf 0.1 gf 0.001 N |
| ZTA-DPU-4 | 4.400 lbf 2.000 kgf 20.00 N |
0.001 lbf 0.001 kgf 0.01 N |
| ZTA-DPU-11 | 11.00 lbf 5.000 kgf 50.00 N |
0.001 lbf 0.001 kgf 0.01 N |
| ZTA-DPU-44 | 44.00 lbf 20.00 kgf 200.0 N |
0.01 lbf 0.01 kgf 0.01 N |
| ZTA-DPU-110 | 110.0 lbf 50.00 kgf 500.0 N |
0.1 lbf 0.01 kgf 0.01 N |
| ZTA-DPU-220 | 220.0 lbf 100.0 kgf 1000 N |
0.1 lbf 0.1 kgf 1 N |
| ZTA-DPU-550 | 550.0 lbf 250.0 kgf 2500 N |
0.1 lbf 0.1 kgf 1 N |
| ZTA-DPU-1100 | 1100 lbf 500.0 kgf 5000 N |
1 lbf 0.1 kgf 1 N |
| ZTA-DPU-2200 | 2200 lbf 1000 kgf 10.00 KN |
1 lbf 1 kgf 0.01 KN |
| ZTA-DPU-4400 | 4400 lbf 2000 kgf 20.00 KN |
1 lbf 1 kgf |
