The LDT can be used to locate leaks in

• pneumatic systems
• vacuum equipment
• valves and fittings
• steam pipes
• oxygen sockets in hospitals
• air conditioning systems in automotive vehicles
• Door and window seals of cars, pressurized containers, ships, trucks, buses, trains, airplanes etc.

For difficult to reach locations we offer a longer goose neck probe as well as a parabolic dish with integrated ultrasonic sensor and laser pointer. The integrated laser pointer makes it easy to trace leaks over distances from 20m to more than 100m for bigger leaks. The parabolic dish is made of transparent plastic, so that the leaks are easily visible. All incoming ultrasonic waves are reflected from the dish and focused at the ultrasonic receiver. Noise is ignored.

Complete Kit

The LDT is supplied as a complete kit with 110mm probe, pin-point detection probe, headphones and calibration certificate in a fitted carrying case.

The post LDT
Ultrasonic Leak Detector first appeared on EgeRate Elektronik.

5 Models Available:
SPG: Integrated Probe, 500 micron / 20 mil range, 60° angle
SPG-S: Cabled Probe, 500 micron / 20 mil range, 60° angle
SPG-OS: Cabled Probe, for Convex Surfaces, 500 micron / 20 mil range, 60° angle
SPG-CS: Cabled Probe, for Textured Coatings, 1500 micron / 60 mil range, 60° angle
SPG-TS: Cabled Probe, for Concrete, 6 mm / 250 mill range, 60° angle

Conforms to ASTMD4417-B, ASTM D8271 (SPG TS only), AS 3894.5-C (with optional 30° tip), U.S.Navy NSI 009-32, Navy NAVSEA 009-32, US Navy NAVSEA PPI 63101-000, SSPC PA 17, SANS 5772, and others. Conforms to ASTM D4417-B, AS 3894.5-C (with optional 30° tip angle), U.S. Navy NSI 009-32, SANS 5772 and others.

The post Positector SPG
Surface Profile Gauge first appeared on EgeRate Elektronik.

Additional probes & Transducers are optionally available where regular checks need to be made from fixed Transducers attached to machine, this method provides more accurate & consistent results.

The post VIBCHECK
Portable Vibration Meter according t... first appeared on EgeRate Elektronik.

In addition to standard approaches, the MK-21uniquely checks machinery condition, in the Diagnostic mode, without reference to a chart … as easy as reading a, bb, ccc and dddd on the display – where a = Quite Good (Zone A), bb = Good (Zone B), ccc = Poor (Zone C) and dddd = Bad (Zone D).

Condition Zones A,B,C & D cover those vibration velocity ranges noted in ISO 10816.

		Low Range	HI Range
Measuring Range	ACC	0.0 ~ 20.0 m/s²	0 ~ 200 m/s²
	ACCP	0.0 ~ 20.0 m/s²	0 ~ 200 m/s²
	VEL	0.0 ~ 20.0 mm/s	0 ~ 200 mm/s
	DISP	0 ~ 200 µm	0 ~ 1990 µm
Frequency Range	ACC	1k ~ 20kHz
	ACCP	1k ~ 20kHz
	VEL	10 ~ 1kHz
	DISP	10 ~ 1kHz

Complete Kit

The MK-21 is supplied as a complete kit with the gauge and wrist strap, probe and cable assembly, batteries and instruction manual — all supplied in a fitted, hard plastic carrying.

The post MK-21
Vibration Meter first appeared on EgeRate Elektronik.

NOTE: Shown with Optional Knurled Aluminum Wheel – LMA-3

The post DLM-107A
Digital Length Meter first appeared on EgeRate Elektronik.

The DFX-8 combines the two types of gauges into one powerful and full featured instrument, that’s equipped with a number of comprehensive toolkits to provide the user the arsenal necessary to address a number of common field applications.

also known as FD800

The post DFX-8
Flaw Detector and Ultrasonic Thickness ... first appeared on EgeRate Elektronik.

The DFX-7 has the ability to simultaneously measure coatings and material thicknesses while maintaining the ability to locate pits, flaws and defects in the material. Based on the same operating principles as SONAR, the DFX-7 is capable of measuring the thickness of various materials with accuracy as high as ± 0.001 inches, or ± 0.01 millimeters. The principle advantage of ultrasonic measurement over traditional methods is that ultrasonic measurements can be performed with access to only one side of the material being measured.

There are two versions of the DFX-7 series: DFX-7 and DFX-7+. The DFX-7 is a wide band only gauge, which includes a single wide band filter with a range of 1.8MHz to 19MHz. The DFX-7+ includes the same wide band filter, but also includes a few narrow band filter options at 2MHz, 5MHz and 10MHz. The wide band option is responsive to all signals within the given frequency range. However, narrow band filters eliminate signals outside of the target filter frequency, and focus on the output of the transducer at the specified frequency.

The post DFX-7
Ultrasonic Flaw Detector and Thickness ... first appeared on EgeRate Elektronik.

In non-contact mode the tachometer measures RPM up to 99,999 RPM at distances up to 13 feet or 500 cm. The DT-2100 can also measure contact RPM, surface speed, or length using the supplied screw-on adapter.

Data logging can be set for single point or continuous logging. Single data points as well as statistics (Max, Min, Average) can be stored in the built-in memory and recalled to the display. Often users need to adjust machinery during testing, with the DT-2100 you can mount it on a tripod, select continuous logging and adjust machinery as necessary. After the test, you can easily review the data on the DT-2100’s display or download to a computer using the optional Windows Software.

The DT-2100 is supplied as a complete kit with 2 cone tip adapters, funnel tip adapter, shaft extension, 6 inch circumference surface speed wheel, reflective tape, 2 AA batteries … all supplied in a foam-fitted carrying case. A NIST-Traceable Calibration Certification is optionally available.

 Complete Kit

The DT-2100 is supplied as a complete kit with tachometer, 2 cone adapters, funnel adapter, 3.5” extension shaft, surface speed wheel (6” circumference), reflective tape, 2 AA batteries, contact adapter in a foam-fitted carrying case

The post DT-2100
Tachometer with USB Output – Co... first appeared on EgeRate Elektronik.

The PLT-5000 is extremely easy to operate and quickly converts from non-contact operation to contact operation by screwing the contact adapter in place. In addition to RPM’s, a wide variety of engineering units for surface speed and length are user-selected via the front panel buttons. Units include; feet per minute, meters/min, yards per minute, inches per minute and more.

A built-in memory stores up to 10 measurements plus minimum, maximum, average and last.

 Complete Kit

The PLT-5000 comes as a complete kit with storage case, 6″ circumference wheel, Funnel Adapter, Cone Adapter, Contact Adapter, three (3) AA Batteries, reflective tape, NIST certificate and instruction manual.

The post PLT-5000
Combination Contact and Non-Contact ... first appeared on EgeRate Elektronik.

NSN 6680-01-378-6490 (DT-205LR)
NSN 6680-01-507-0818 (DT-207LR) DT-207LR-12 = Avtron M740

 LCD Display vs LED Display

 Complete Kit

All models are supplied as a complete kit including the tachometer, reflective tape, screw-in contact adapter, 2 cone tips, funnel tip, shaft extension, surface speed wheel, two AA batteries, NIST traceable calibration certificate and an operating instruction manual – all supplied in a foam-fitted carrying case.

Note: On DT-205LR-12 and DT-207LR-12 models 12″ circumference wheel is supplied instead of 6″ version

The post DT-205LR – DT-207LR
Combination Contact... first appeared on EgeRate Elektronik.
